Key Features & Advantages
Precision 5-Axis Machining
Supports complex surfaces, multi-angle features, and high-precision contour parts in a single setup.
01
High-Speed Spindle
Maximum spindle speed: 20000 rpm for high-speed precision machining of complex parts.
02
Rotary Table
The B/C-axis rotary table is suitable for complex contours, multi-surface work, and multi-angle features.
03
Rapid Traverse
X/Y/Z rapid traverse: 48/48/48 m/min, helping improve overall cycle time in complex-part machining.
04
Tool Change System
A 24T tool magazine supports continuous multi-process machining of precision parts.
05
Applications
- Complex Curved-Surface Parts Machining
- Impellers and Blades Machining
- Propellers Machining
- Motor Rotor Machining
- Crankshaft Parts Machining
- Precision Mold Machining
Machinable Materials
Aluminum Alloy
Stainless Steel
Titanium Alloy
Tool Steel
Engineering Plastics
Manufacturing Capability
- In-house machining and assembly
- Precision inspection with CMM (coordinate measuring machine) and laser interferometer
- ERP-based production process management
- Complete machine manufacturing capability
After-Sales Service
- One-year warranty for the complete machine and CNC system
- Remote technical support within 4 hours
- On-site service within 48 hours when required
- Includes installation, commissioning, and operator training
Delivery & Terms
Lead time: 30-60 days
Installation support available
Custom configurations available
Honor and qualification
Utility Model Patent Certificate
Utility Model Patent Certificate
Utility Model Patent Certificate
Invention Patent Certificate
Invention Patent Certificate
Technical Specification
|
Item |
Unit |
5 Axis Machining Center Precision |
|
X-Axis Travel (Saddle Left-Right Movement) |
mm |
560 |
|
Y-Axis Travel (Column Front-Back Movement) |
mm |
400 |
|
Z-Axis Travel (Spindle Box Up-Down Movement) |
mm |
400 |
|
Distance from Worktable Surface to Spindle End Face |
mm |
150-550 |
|
Worktable Size |
mm |
Φ300/400 |
|
Worktable Load Capacity |
kg |
200 |
|
Worktable Speed (Tilt Axis B-Axis) |
rpm |
20 |
|
Worktable Speed (Rotary Axis C-Axis) |
rpm |
150 |
|
Maximum Cutting Speed |
- |
1-20000 |
|
Rapid Traverse Speed X/Y/Z |
m/min |
48/48/48 |
|
Drive Mode |
- |
Direct Drive |
|
Maximum Spindle Speed |
- |
20000 |
|
Spindle Power |
rpm |
9.0/13 (1PH8107) |
|
Spindle Taper Hole |
kw |
BT40 |
|
Tool Magazine Capacity |
mm |
24T |
|
Tool Holder Type |
- |
BT40 |
|
Maximum Tool Diameter (Full Tool / Empty Station) |
mm |
80/150 |
|
Maximum Tool Length |
mm |
300 |
|
Maximum Tool Weight |
kg |
8 |
|
Total Power Capacity |
KVA |
50 |
|
Machine Overall Dimensions |
mm |
250029502900 |
|
Machine Weight (Approx.) |
kg |
6500 |
